3mm 0.1MPa 2 Wire Ultrasonic Submersible Level Sensor

3mm 0.1MPa 2 Wire Ultrasonic Submersible Level Sensor

Ultrasonic Submersible Level Sensor

2 Wire Submersible Level Sensor

0.1MPa Wastewater Level Sensor

مكان المنشأ:

الصين

اسم العلامة التجارية:

WNK

إصدار الشهادات:

CE

رقم الموديل:

ونك-YTS56

اتصل بنا
اطلب اقتباس
Product Details
الإخراج التناظرية:
2 سلك 4 ~ 20mA / 250Ω تحميل، 4-سلك 4 ~ 20mA / 510Ω تحميل
مزود الطاقة:
24 فولت تيار مستمر
عملية الضغط:
-0.02-0.1MPA
حجم التثبيت:
خيط أو فليانج
الإخراج الرقمي:
اختياري 485، 232
دقة:
3 ملم أو 0.1%
فئة الحماية:
أداة العرض -20 ~ + 60 درجة مئوية، المسبار -20 ~ + 80 درجة مئوية
نطاق القياس:
0.5%~1.0%
إبراز:

Ultrasonic Submersible Level Sensor

,

2 Wire Submersible Level Sensor

,

0.1MPa Wastewater Level Sensor

Payment & Shipping Terms
الحد الأدنى لكمية
1 قطعة
تفاصيل التغليف
تعبئة كرتون محايدة أو حسب متطلباتك.
وقت التسليم
5-8 أيام عمل
شروط الدفع
د / ف، / تي تي، ويسترن يونيون، بايبال
القدرة على العرض
5000/ قطعة/ شهر
RELATED PRODUCTS
اتصل بنا
اتصل بنا الآن
Product Description

2 Wire 4-20mA Ultrasonic Liquid Fuel Water Level Sensor /Meter

Product Description

The integrated ultrasonic liquid level gauge is a low-cost measuring device for measuring liquid, slurry and solids on the industrial site. A large number of applications in water treatment, municipal, chemical, machinery manufacturing industries





Features Integrated
Range 5m, 10m, 15m,20m,30m,40m,50m,60m
Measurement accuracy 0.5%-1.0%
Resolution 3mm or 1%(whichever is greater)
Display chinese Led or English Led
Analog output 2 wire 4 ~ 20mA / 25Ω load, 4 wire 4 ~ 20mA / 510Ω load
Digital output Optional 485, 232
Relay output Optional 2 sets of AC 250V / 5A or DC 30V / 5A
Powered Standard 24VDC, optional 220V AC + 15% 50HZ
Ambient temperature Display instrument -20 ~ + 60 ℃, probe -20 ~ + 80 ℃
Protection class Display instrument IP65, probe IP68
Probe Cable No
Installation size Thread or flange



3mm 0.1MPa 2 Wire Ultrasonic Submersible Level Sensor 03mm 0.1MPa 2 Wire Ultrasonic Submersible Level Sensor 1

Company Information

3mm 0.1MPa 2 Wire Ultrasonic Submersible Level Sensor 2

FAQ



Q: Are you manufacturer or trading company?

A: We are professional pressure/level/temperature measurement manufacturer with more than 13 years of experience. Our factory address is: 4/F,Bldg #6, No.168, Xiangzhang Road, High-tech District, 230088, Hefei, Anhui province, China.



Q: What’s your quality control system?

A: We are an ISO 9001-2015 certified manufacturer, we have strict quality control system. Besides clibartiaon, each set product we also do temperature compensation and aging test before shipment, so the quality is guaranteed.



Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.



Q: Can we use our logo on the products? Do you provide customized products?

Yes.we can use your logo, we can provide customized products per requirement. OEM/ODM is welcome



Q: What is yor MOQ?

A: We have no MOQ limits, small quantity order is acceptable.



Q: What's the transport?

A: Express such as DHL, Fedex, TNT, UPS for freight prepaid, also can use your own couier account to do the freight collect. For more goods we can arrange by air or by Sea.
