macro 30KPA Electronic Differential Pressure Flow Transmitter

macro 30KPA Electronic Differential Pressure Flow Transmitter

30KPA electronic differential pressure transmitter

30KPA differential pressure flow transmitter

macro differential pressure level sensor

مكان المنشأ:

خفى، الصين

اسم العلامة التجارية:

WNK

إصدار الشهادات:

CE

رقم الموديل:

WNK268/WNK808B

اتصل بنا
اطلب اقتباس
Product Details
رقم الموديل:
WNK268/WNK808B
نوع الضغط:
ضغط المقياس والضغط التفاضلي
وسائط:
الهواء والغاز
إشارة الإخراج:
4- 20 مللي أمبير
نطاق الضغط:
-100Kpa ~ 60MPa
دقة:
0.2%، 0.5% خ
درجة حرارة التشغيل:
-40~85 درجة مئوية
درجة حرارة العمل:
-10 ~ 70 درجة
الوزن الصافي:
347.5 جرام
مكان المنشأ:
الصين
إبراز:

30KPA electronic differential pressure transmitter

,

30KPA differential pressure flow transmitter

,

macro differential pressure level sensor

Payment & Shipping Terms
الحد الأدنى لكمية
1 قطعة
الأسعار
negotiable
تفاصيل التغليف
مربعات
وقت التسليم
5-8 أيام عمل
شروط الدفع
T/T ، Western Union ، PayPal ، بطاقة الائتمان
القدرة على العرض
2000 قطعة في الأسبوع
RELATED PRODUCTS
اتصل بنا
اتصل بنا الآن
Product Description

4-20mA Differential Pressure Transmitters For Gas Differential Pressure Measurement

Product Description



Intelligent Macro Differential Pressure Transmitter
Applicable media
Gas, Steam
Pressure Measurement
Gauge pressure, Differential pressure
Pressure range
-10Pa~100Pa, -100kPa~+100kPa
Accuracy
0.2%, 0.5%
Stability
0.8%F.S./Year
Maximum static pressure
70 KPa
Max overload
250% of sensor range
Output signals
4~20mA
Housing material
Aluminum14
Induct Pressure Connection:
M 8x1 female or Ø 8 dowel connection

Power Supply
Non-explosion: 10.5~45V DC
EEX ia:10.5~30 V DC
Ambient temperature
-40~85℃
Compensation temperature
-10~70℃
Working temperature
-10~70℃





WNK808B intelligent pressure transmitter is assembled with aluminum housing and stress isolation technology. Integrated structure design lead to compact layout. With intelligent compensation technology, it is suitable for wind pressure,wind speed & flow measurement. It is widely used in various industrial fields as well as intelligent building and other construction projects, such as power plant boiler primary air,secondary air measuring, mine ventilation,indoor ventilation, boiler air, pressure of fan, air duct pressure, Metro wind pressure and environment wind pressure test.



Application


It is the best micro pressure measurement equipment for textile machinery,natural gas pipeline monitoring,dust removal system, HVAC,clean laboratory and medical equipment etc.



Product Show

macro 30KPA Electronic Differential Pressure Flow Transmitter 0macro 30KPA Electronic Differential Pressure Flow Transmitter 1macro 30KPA Electronic Differential Pressure Flow Transmitter 2macro 30KPA Electronic Differential Pressure Flow Transmitter 3

macro 30KPA Electronic Differential Pressure Flow Transmitter 4macro 30KPA Electronic Differential Pressure Flow Transmitter 5

macro 30KPA Electronic Differential Pressure Flow Transmitter 6
macro 30KPA Electronic Differential Pressure Flow Transmitter 7






Company Information

macro 30KPA Electronic Differential Pressure Flow Transmitter 8



Exhibition

macro 30KPA Electronic Differential Pressure Flow Transmitter 9





Certification

macro 30KPA Electronic Differential Pressure Flow Transmitter 10




FAQ

Q: Are you trading company or manufacturer ?

A: We are a manufacturer since the year 2004, committed to producing high accuracy, long-term stability, cost-efficient pressure/level/temperature measuring instruments.

Q: What's your quality control system?

A: Our factory is cerrified under ISO 9001-2015. All products are completed with temperature compensation and 48 hours aging test before shipment.

Q: What is the warranty of your products?

A: 12 month from shipment date, for non-man-made damages.

Q: Shipping and Delivery

A: Small orders are delivered with DHL, Fedex, TNT, UPS , with delivery time in 4 - 5 business days.

Large orders are recommended to ship by sea
